1.2x0.7x0.6 m
Provides 70 dB attenuation between 1 and 10 GHz, ideal for large equipment, with top access and powerful ventilation.
The Ranatec 1.2×0.7×0.6 m Shield Box is a spacious RF enclosure offering 70 dB attenuation between 1 and 10 GHz. It is designed for large equipment such as base stations and microwave links, with top access for easy placement. A high-capacity cooling fan handles up to 2000 W of generated heat, and it supports various interfaces including LAN, USB, and HDMI, ensuring versatility in testing environments.
The RI 189 is designed for shielding over all cellular mobile frequency bands, 1-10 GHz making it suitable for applications such as:
| Attenuation | 70 dB at 1-10 GHz |
| Inner dimensions | 1.2 x 0.7 x 0.6 m |
| Outer dimensions | 1.3 x 0.8 x 0.7 m |
| Weight (standard) | 32.2 kg |
| Material | Aluminum |
All electrical interfaces are located on a replaceable interface plate. The interface plate can be equipped with various I/O interfaces and connectors. Please see further details under the ordering column.
